Test of Steel Truss Bridge with Locomotive Loading
Date:
circa 1917
Description:
Sepia-toned photograph showing test of a steel truss bridge in White Heath, IL with locomotive loading. The caption notes that slight changes in the bridge's form, in its posts and chords, were measured with special micrometers. The two unidentified men on the scaffolding were measuring the compression in a vertical post.
