Title:
Centrifugal Pump, Pump Testing Floor
Date:
circa 1917
Description:
Sepia-toned photograph showing centrifugal pump, driven by a steam engine. The power delivered to the pump was measured by a steam engine indicator; the quantity of water delivered measured by a weir; and the steam pressure measured by a gauge.
Found in RS 11/1/10, Vol. 4
Phys. Desc:
Tiff
Image measures 23.6 x 18.4 cm
ID:
0005662
Repository:
University of Illinois Archives
Found in:
11/1/10 Photograph Album, 1915-17
Subjects:
Rights:
Copyright of this image is held by the University of Illinois. Please contact us if you would like to purchase a high-resolution copy of the image.
