Title:
Assembly Schedule for Gas Engine
Date:
circa 1917
Description:
Sepia tone photograph showing operation order for manufacture of crankcase, pump, crankshaft, and cylinder for gas engines, with final assembly view of engine at bottom
Found in RS 11/1/10, Vol. 3
