Rig for Testing Concrete Beam under Long-Continued Load | University of Illinois Archives

Title:
Rig for Testing Concrete Beam under Long-Continued Load
Date:
circa 1917
Description:

Sepia-toned photograph showing device for testing stress in a concrete beam. The screw jack at the right applies the load, measured by the deflection of the heavy flat spring at the top. The spiral spring at the left takes up the "play" of the nuts, keeping the load on the beam constant. The device was designed and built in the materials science laboratory.

Found in RS 11/1/10, Vol. 4

Phys. Desc:

Tiff

Image measures 16.9 x 11.1 cm

ID:
0005687
Repository:
University of Illinois Archives
Found in:
Subjects:
Rights:
Copyright of this image is held by the University of Illinois. Please contact us if you would like to purchase a high-resolution copy of the image.
