Plan for Dispatching Work through Machine Department
Sepia tone photograph showing diagram of parts production, from initial work order, manufacture, and inspection prior to sending part to next machine
Found in RS 11/1/10, Vol. 3
Image Measures 14.1 x 10.8 cm
University of Illinois Archives
11/1/10 Photograph Album, 1915-17
