Micrometer "Extensometer" for Measuring Steel Stretching | University of Illinois Archives
Title:
Micrometer "Extensometer" for Measuring Steel Stretching
Date:
circa 1917
Description:
Sepia-toned photograph showing apparatus, designed and built in the materials science laboratory, used to measure stretches in steel to an interval of one ten-thousandth of an inch. The device can be seen in use in DB image #5669
Found in RS 11/1/10, Vol. 4
Phys. Desc:
Tiff
Image measures 16.8 x 11.2 cm
ID:
0005680
Repository:
University of Illinois Archives
Found in:
11/1/10 Photograph Album, 1915-17
Subjects:
Rights:
Copyright of this image is held by the University of Illinois. Please contact us if you would like to purchase a high-resolution copy of the image.
